315mm Fabrication Welding Machine For Tee Cross Elbow Y Fittings

Large Image : 315mm Fabrication Welding Machine For Tee Cross Elbow Y Fittings

Product Details:

Place of Origin:	China
Brand Name:	MM-Tech
Certification:	ISO,CE,
Model Number:	SWT-MA315

Payment & Shipping Terms:

Minimum Order Quantity:	1set
Price:	$12500-$16000 per set
Packaging Details:	Plywood Case With Pallet
Delivery Time:	5-8 work days
Payment Terms:	T/T, Western Union,
Supply Ability:	100 sets per week

Contact Now

Detailed Product Description

Product Name:	Fabrication Welding Machine	Pipe Sizes:	90,110,125,140,160,180,200,225,250,280,315
Working Voltage:	380V ±10%	Rated Frequency:	50/60Hz
Heating Plate Max. Temp:	270 Degree	Total Power:	7.25KW
Facer Power:	3 KW	Temperature Tolerance::	<5℃
Pressure Adjustable Ranges:	6MPa
Highlight:	315mm fabrication welding machine , tee fabrication welding machine , cross fabrication welding machine

315mm Multi-Angle Workshop Fitting Welding Machine For Tee Cross Elbow And Y Fittings

Workshop Fitting Fusion Machine Introduction:

1.The machine is used to weld pipes made from PE,PP,PVDF and can not be used to weld material without description otherwise the machine may be damaged or some accident may be resulted in.
2.Don't use the machine in a place with potential hazard of explosion.

Workshop Fitting Fusion Machine Specification:

Rated Voltage:	380v
Rated Frequency:	50/60Hz
Pressure Range:	0-16Mpa
Rated Power:	29.23KW
Heater Power	22.23KW
Facer Power	3KW
Hydraulic Power	4KW
Max. Temperature:	270℃
Temperature Tolerance:	<5℃
Applicable material:	HDPE, PB,PVDF
Welding Diameter:	90mm to 315mm
Packing:	Wooden Case
OEM:	Available
Gw.:	3510kg
Volume:	20.4CBM
Include:	1.1 machine set with hydraulic unit facer, heater plate and tools 2.1 cross clamps 3.1 elbow clamps

Our Request:

1.Special clamps for welding flange stub
2.Special clamps for short spigot fitting
3.Special clamps for welding Y shape(45 and 60)fitting
4.Data logger and printer

Package & Delivery:

315mm Fabrication Welding Machine For Tee Cross Elbow Y Fittings 0

Features:

1. Suitable for fabricating Elbow, Tee, Y shape(45" and 60°) fittings of PE PP PVDF in workshop.
2. Integrated structure, nothing remains but to choose the different special clamps while fabricating different fittings.
3. Consists of Basic Frame, Hydraulic Unit, Trimmer, Heater and Electric Control Unit.

4. Removable PTFE coated heating plate with
separate temperature control system.

5. Electric Trimmer with reversible double cutting edge blades.

6. Hydraulic unit provides welding machine with compressing power.

7. Low starting pressure ensures reliable welding quality of small pipes.

8. Including the Temperature Controller and Timer, easy to know the time and temperature.

Products:

315mm Fabrication Welding Machine For Tee Cross Elbow Y Fittings 1

Advantages:

1. Workshop fitting welding machine with printing is suitable for fabricating elbow, tee, cross and wye shape (45 and 60) Fittings of PE, PP, PVDF in workshop

2. Base on the integrated design, if welded different fitting you just need to replace the corresponding fixture

3. Heating plate uses independent temperature control svstem. removable PTFE coated.

4. Electric facer with safety limit switch can avoid the milling cutter accidental starting5. Low starting pressure ensures reliable welding quality of small pipes.

Service:

Standard:Approved by ISO9001, CE,SGS,ROSH,EMC standard

Machine Quality Guarantee : 24 months.--- If any parts broken or does not work under normal operating, we are free to provide.
