ISO Approved Saddle Fusion Machine With Removable PTFE Coated Heating Plate

Large Image : ISO Approved Saddle Fusion Machine With Removable PTFE Coated Heating Plate

Product Details:

Place of Origin:	Hebei,China
Brand Name:	MM-Tech
Certification:	ISO,CE,
Model Number:	SWT-S450W

Contact Now

Detailed Product Description

Ambient Temperature::	-5~45℃	Weight::	1900KG
Drill Motor Power:	1.5~3Kw	Hydraulic Unit Power:	1.5Kw
Heating Plate Power:	8~12Kw	Ambient Temperature:	-5~45℃
Highlight:	ISO Saddle Fusion Machine , Saddle Fusion Machine Removable Heating Plate

Saddle Fusion Welding Machine SWT-S450W

Features

The saddle pipe fusion machine has a removable PTFE coated heating plate.

It has a separate two-channel timer that records times in soaking and cooling phases.

The digital high-accurate pressure meter of the saddle pipe fusion machine indicates clearer readings.

The linear guide ways are equipped with a heating plate and dragging plate.

ISO Approved Saddle Fusion Machine With Removable PTFE Coated Heating Plate 0

Applications

The saddle pipe fusion machine is used for fabricating PE reducing tee in a workshop.

The integrated function of welding and taping enables it to complete the whole fabricating process.

Technical Parameters of the Saddle Pipe Fusion Machine

Fitting type:Manhole

Main pipe max. dia.:630mm/800mm/1000mm/1200mm

Branch pipe max. dia.315mm/400mm/500mm/560mm

Ambient temperature:-5~45℃

Heating plant max. temp.:270℃

System pressure ranges:0-16Mpa

Working voltage:380V±10%, 50Hz

Heating plate power:8~12Kw

Hydraulic unit power:1.5Kw

Drill motor power:1.5~3Kw

Total power:11~16.5Kw

Weight:1900KG

Tag:

Contact Person: Wilson Zhou

Tel: +8613731081806

Fax: 86-311-68009658
