Touch Panel Plastic Film Leak Detector For Test Geomembrane

Plastic Film Leak Detector MMT-7DJ Plastic Film Leak Detector For Test Geomembrane

Plastic Film Leak Detector​ Introduction:

MMT-7DJ Plastic Film Leak Detector is a high-pressure instrument. It is a testing equipment used to detect the surface integrity of leaking plastic film and impermeable film. It can identify damage points of any size caused by transportation, installation and use, and maintenance of the plastic film.

Plastic Film Leak Detector​ Technical Data:

1. Output high voltage: 1KV～50KV (continuously adjustable)
2. Direct indication of output high voltage value, voltage accuracy ±1%
3. Detection thickness ≤35mm
4. Variable sensitivity
5. Battery: 12V/2200mA
6. Power consumption: ≤5W
7. Host volume: 220 × 130 × 88 mm3
8. Backlight
9. Leak point count: maximum 999
10. Turn on instantaneously, turn off automatically when power off
11. Three-digit LCD display output voltage, full touch panel
12. Alarm: buzzer alarm

Plastic Film Leak Detector​ Packing:

1 Black Plastic Box Inside and 1 Carton Outside

Plastic Film Leak Detector​​ Delivery:

It usually takes 8 - 10 days to your office in South America, Asia, Europe, North America, South Africa by FedEx express from Beijing,China.

After-sales service:

24 months -- If any parts broken or doesn't work under normal operating, we will provide them for free.

Plastic Film Leak Detector​ FAQ:

1. Is it only suitable for plane detection? What are the requirements for terrain?
2. Can the weak spot of the membrane welding be detected?
3. By what principle is the alarm sound?
4. What is the principle of leak detection?
5. Suitable for soil, cement (wet ground or metal material?)

• The outside soil surface is almost the surface after construction machinery construction, right? Of course, the flatter the better, the better to detect. You can press the probe brush on the geomembrane a little bit harder.
• Welding is not strong and cannot be inspected, only the leakage of the membrane can be measured.
• Buzzer alarm.
• Principle of pulse voltage.
• Yes, the wetter the ground, the better the inspection, the stronger the conductivity

Plastic Film Leak Detector​ Application:
