Hemispherical Vacuum Air Leak Tester For Waterproofing Membrane Test

Large Image : Hemispherical Vacuum Air Leak Tester For Waterproofing Membrane Test

Product Details:

Place of Origin:	HEBEI, CHINA
Brand Name:	MM-TECH
Certification:	CE
Model Number:	SWT-NS003

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	US$750 - 900 /SET
Packaging Details:	1 Alloy Box and 1 Carton
Delivery Time:	Within 7 days
Payment Terms:	T/T, Western Union, PayPal
Supply Ability:	9,000 sets / per month

Contact Now

Detailed Product Description

Model:	SWT-NS003	Dielectric Strength:	1500V/50HZ 1min No Breakdown
Thermo Protector:	Anto Reset 130±5°C	Shape:	Hemispherical
Max.air Volume:	≤30L/min	Noise:	≤48dB(A)
Frequency:	50/60Hz	Testing Size:	700cm2
Max. Vacuum:	-84Kpa	Temperature For Using:	5-40°C
Isullation:	B Class	Voltage:	230V
Highlight:	Hemispherical Vacuum Air Leak Tester , Hemispherical Air Leak Tester , Vacuum Air Leak Tester For Membrane

Testing Vacuum Air Leak Tester for Waterproofing Membrane Weld Test Tool

Vaccum Leak Test Tester Presentation:

Vaccum leak tester is designed as CJJ113-2007 standard from National construction department,which is small body and strong negative pressure.The vaccum part is of blow moulding acrylic.The whole vaccum is clean and strong resistant,connected with special strip seal.It is used in disposal landfill project and roof waterproofing check.

Vaccum Leak Test Tester Technical Data:

Voltage:	230V
Frequency:	50/60HZ
Max. negative pressure:	84kpa
Normal testing negative pressure:	20-40kpa
Effective leak testing size:	Φ280mm
Size of the vaccum:	Φ360mm
Connecting way bewteen vaccum and pump:	quick connector
Weight:	5.8kgs
Shape:	Hemispherical

Precautions:

(1)Test pin should be properly and cleanly kept . Shall handled carefully to avoid damage.

(2)Generally the pressure of needle is appropriate at 3/ 4 of cap , not necessary full . The instrument should be checked regularly to ensure the accuracy..

Construction of the scene:

Hemispherical Vacuum Air Leak Tester For Waterproofing Membrane Test 0

Exhibition:

Hemispherical Vacuum Air Leak Tester For Waterproofing Membrane Test 1

Service:

24 months. -- If any parts broken or doesn't work under normal operating, we will provide them for free.
