SWT-NS700 0.5-3mm PVC Geomembrane Welding Machine For Damliner

Large Image : SWT-NS700 0.5-3mm PVC Geomembrane Welding Machine For Damliner

Product Details:

Place of Origin:	China
Brand Name:	MM-TECH
Certification:	CE
Model Number:	SWT-NS700

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	2500
Packaging Details:	aluminum box
Delivery Time:	5-8 work day
Payment Terms:	T/T,Western Union
Supply Ability:	1000sets/week

Contact Now

Detailed Product Description

Power:	2800W	Model:	SWT-NS700
Voltage:	230v	Frequency:	50/60HZ
Weight:	7.5kg	Overlap Width:	16cm
Seam Width:	15mm*2,interrior Cavity 15cm	Welding Thickness:	0.5-3mm
Welding Speed:	0.5-3.5m/min

SWT-NS700 PVC 0.5-3MM Geomembrane Welding Machine for Damliner

Product Overview

The SWT-NS700 welding machine adopts advanced heat chip structure with high power and high pressure, offering fast welding speeds suitable for 0.5-3.0mm thick film material. It is designed for welding HDPE, LDPE, PVC, EVA, ECB, PP and other hot melt materials.

Technical Specifications

Attribute	Value
Model	SWT-NS700
Voltage	230v
Frequency	50/60HZ
Power	2800W
Weight	7.5kg
Overlap width	16cm
Welding speed	0.5-3.5m/min
Temperature	50-620℃
Seam Strength	≥85% Original
Seam width	15mm*2, Interior Cavity 15mm
Welding thickness	0.5-3mm
Feeding method	Same side & Two sides
Digital display	Temperature & Speed

Applications

Products are used in water conservancy, aquaculture, landfill, chemical and mining, sewage treatment, roof construction and other fields of waterproof and seepage control engineering.

Product Features

CONTROL SYSTEM

Advanced digital display, accurate control and strong protection.
MOTOR SYSTEM

High power and torque motor combined with double precise driving motion, which makes it weld on steep. Welding speed is adjustable.
PRESSURE ROLLER

Special stainless steel pressure rollers has advantage of strong pressure force, anti-skid and durability.
HOT AIR SYSTEM

The hot air heating system makes sure it is good to weld corrosive membranes or operate in terrible environment.
DRIVING MOTOR

Hitachi drill with reliable quality and strong power.
