3-30mm Plastic Sheet Welding Machine For PP Sheet

Large Image : 3-30mm Plastic Sheet Welding Machine For PP Sheet

Product Details:

Place of Origin:	China
Brand Name:	MM-TECH
Certification:	CE
Model Number:	SWT-PH3000

Payment & Shipping Terms:

Minimum Order Quantity:	1set
Price:	$20,000.00-$26,000.00 set
Packaging Details:	Wooden Box
Delivery Time:	approximately 30 days after supplier received buyer's advance payment
Payment Terms:	T/T, Western Union, PayPal, Alibaba, Credit Card
Supply Ability:	300 sets per year

Contact Now

Detailed Product Description

Product Name:	Sheet Butt Fusion Welding Machine	Rated Voltage:	380V/415V, 3P, 50/60Hz
Optional Device:	90° Vertical Welding	Packing Diamensions:	482182162CM
Weldable Working Length:	3000mm	Roll Circle Diameter Minimum:	350mm
Welding System:	CNC	Rolling Motor Power:	4.4 KW
Warranty:	2 Years	CE Certification:	Yes
Highlight:	3mm plastic sheet welding machine , 30mm pp sheet welding machine , whole heating plastic sheet welding machine

3-30mm Plastic Sheet Welding Machine For PP Sheet

Plastic Sheet Welding Machine Descriptions:

This plastic sheet welding machine is suitable for welding thermoplastic sheets made of PE, PP
PVC, PVDF, PC, ABS, Acrylic. lt could not only support horizontal & circular welding, but also
support 90° vertical jointing of the sheets on customer's request.

Plastic Sheet Welding Machine Technical Parameters:

Weldable Materials	PE, PP, PVC
Max. Working Length(mm)	3000mm
Weldable Thickness(mm)	Hard Sheet: 3-50mm
Min. Cylinder Diameter(mm)	350mm
Pressure Setting Method	Digital
Pressure Controller	SMC electrical proportional valve
Power Consumption(kW)	6kW
Power Supply	380/415V, 3P, 50/60Hz
Compressed Air Connection(bar)	6-8kg/cm2
Motor of Cylinder	4.4kW

Plastic Sheet Welding Machine Applications:

Plastic Sheet Welding Machine Finished Products:

Plastic Sheet Welding Machine Includes:
